Technical Parameters
| Machine Type | Induction Melting Furnace |
| Brand | WOLFU |
| Capacity | 1kg – 10kg |
| Power | 3kW – 20kW |
| Voltage | 220V / 380V |
| Heating Rate | 3–5 minutes |
| Maximum Temperature | 1450℃ |
| Machine Dimension | 870 × 355 × 400 mm |
| Weight | 20–48 kg |
Material → Process → Final Product
| Raw Materials | Melting Process | Final Products |
|---|---|---|
|
Gold Silver Copper Tin Precious Metal Scrap |
Induction Heating High Temperature Melting Metal Refining Casting |
Molten Metal Metal Ingots Refined Precious Metals |
Model Specifications
| Model | Power | Voltage | Packing Size | Packing Weight |
| 1KG | 3–5 kW | 220V | 710 × 420 × 410 mm | 20 kg |
| 2KG | 3–5 kW | 220V | 710 × 420 × 410 mm | 26 kg |
| 3KG | 7–10 kW | 380V | 650 × 350 × 350 mm | 32 kg |
| 5KG | 10 kW | 380V | 940 × 425 × 470 mm | 38 kg |
| 10KG | 20 kW | 380V | 940 × 425 × 470 mm | 48 kg |
Main Applications
The WOLFU induction melting furnace is suitable for melting various metals including:
- Gold
- Silver
- Copper
- Aluminum
- Tin
- Precious metal alloys
It is widely used in:
- Jewelry manufacturing workshops
- Precious metal refining plants
- Metal casting factories
- Laboratories and research institutes
- Recycling and smelting industries
Key Features
Fast Heating Speed
The induction heating system can melt metals in 3–5 minutes, significantly improving production efficiency.
High Temperature Capability
Maximum working temperature can reach 1450°C, suitable for melting various precious metals.
Digital Temperature Control
Equipped with a digital control system for precise temperature adjustment.
Energy Efficient Design
Induction heating technology ensures low energy consumption and stable operation.
Compact Structure
Small footprint and portable design make it ideal for workshops and laboratories.
